Description
Addressable Sounder Circuit Module Overview
The TX7220 is normally used for overriding equipment such as lift return, door holder, smoke extract fans, air handling unit, auto dialler to fire brigade, BMS and etc. It has built-in feedback signal feature, according to the pre-configured interface module command fire scenario, the alarm controller send out start command to the equipment required to start. After receiving the command, output module enables its relay to change state. Once the module is under control and operated a confirmation signal will be sending back to the alarm controller.
In addition, the TX7220 incorporates an intelligent processor that provides automatic monitoring for both open and short circuit of the input signal line.
The TX7220 is aesthetically pleasing with unobtrusive design that will complement modern building designs and its plug-in type assembles make installation and maintenance more convenient to the installer. The unit is compatible to the TX7004 Analogue Intelligent Fire Alarm Control Panel, produced by single manufacture T&A, to avoid addressable communication compatibility problem.
Features and Benefits
• EN54-18 Compliance
• Built-in MCU processor and digital addressing
• Two circuits 24Vdc/3A Output relay contact and Control module
• Two circuits Input Fire or Supervisory signal configuration
• Dis/Enable Input and output cable monitored
• LED status indicator
• Onsite Adjustable Parameter
• Loop or external power input
• Aesthetically pleasing design
• Surface mounting with fix base for simple installation
