Description
Broadcast Control Panel Overview
The TNA voice alarm system consists of TG7100 control panel, and series of power amplifiers TG7300/TG7301/TG7302 and TX7214 addressable voice alarm module.
The TG7100 consists of recorded emergency messages, emergency microphone, indicators and controls for selecting voice alarm zones and interfaces in a single cabinet.
The TG7100 also supports the public address application for providing background music and non-emergency messages used for malls, hospital, school, factories and buildings.
Features and Benefits
• Three start mode: auto, manual and contact input
• Support multiple audio inputs, such as emergency broadcast, U disk, MIC, external line 1, external line 2
• Provide MP3 and WMA formats
• Supports 10-level cascaded power amplifi-ers
• Large reserved space for broadcast sound, and broadcast sound can be synthesized and imported
• Automatically detect U disk and MIC
• LED for emergency broadcast
• Black and white 128×64 LCD, displaying 32 characters.
