Description
| Compliance | EN54-4 |
| Power Rating | |
| Power Supply | Mains: AC220V (110-240V),50/60Hz, ＜130W(5A),＜270W(10A) |
| Backup | 24VDC/12Ah sealed lead-acid battery (Not included) |
| Output Power | 5A: 120W (24VDC/5A) 10A: 240W (24VDC/10A) |
| PSU | |
| Protocol / Addressing | T&A, Value range from 1 to 254 |
| Mains and backup switching time |
No delay. |
| Indicator | Numerical Display |
| Material / Color | Flat sheet Metal / Light Gray |
| Dimension | 5A: 400mm x 320mm x 120mm 10A: 400mm x 380mm x 135mm |
| IP Grade | IP30 |
| Operating Environment | |
| Temperature | -10℃~+60℃ |
| Relative Humidity | ≤95%, non-condensing |
| Atmosphere | 86~106KPa |
